Automotive Applications and Products

The future of mobility is autonomous, and PCA Electronics, Inc. designs and manufactures complete component solutions for the automotive and transportation market.

Our product line includes transformers, inductors, and common mode chokes. We also have unique custom magnetics, all designed and manufactured to AEC-Q200 qualification standards.

Our experienced design engineers offer solutions to meet your specific needs for the current and future generations of automobiles. The size and capability of our magnetics can be designed to meet the electronics specifications your application requires.

Contact us to learn more about how PCA can optimize your automotive electronic systems.

Buy	Chipset	Controller	PCA Part No.	Topology	Geometry	Turns Ratio	Po	Lp	Vin	Aux	S1	S2	S3	Fsw	ET
		MFG	Part No.			Pri : Aux : S1 : S2 : S3	Watts	uH	Min-Max					KHz	Watts
Per page: Jump to:
	PGA460	Texas Instruments	EPA4488G-LF	BMS	EP5	01:08.4	0.0	3	7.2V		120 Vpk-pk			0	20
	SN6501	Texas Instruments	EPC3667G-LF	Push-Pull	Toroidal	1.000CT : 1.100CT	0.3	1000	3.3V	N/A	3.3V / 0.1A	N/A	N/A	250	7.2
	SN6501,SN6505	Texas Instruments	EPC3668G-LF	Push-Pull	Toroidal	1.000CT : 1.100CT	0.8	1000	5	N/A	5V / 0.15A	N/A	N/A	300	9.2
	SN6501	Texas Instruments	EPC3669G-LF	Push-Pull	Toroidal	1.000CT : 1.700CT	0.5	475	3.3	N/A	5V / 0.1A	N/A	N/A	250	7.2
	SN6501	Texas Instruments	EPC3670G-LF	Push-Pull	Toroidal	1.000CT : 1.300CT	0.5	475	5	N/A	5V / 0.1A	N/A	N/A	250	9.2
	SN6501	Texas Instruments	EPC3671G-LF	Push-Pull	Toroidal	1.000CT : 2.000CT	0.5	475	3.3V	N/A	5V / 0.1A	N/A	N/A	250	7.2
	SN6501,SN6505B	Texas Instruments	EPC3804G-LF	Push-Pull	Toroidal	1.000 : 1.1	0.5	900	3.3V	N/A	3.3V	N/A	N/A	300	11
	SN6501,SN6505B	Texas Instruments	EPC3805G-LF	Push-Pull	Toroidal	1.000 : 1.1	0.8	475	5V	N/A	5V	N/A	N/A	300	11
	SN6501,SN6505B	Texas Instruments	EPC3806G-LF	Push-Pull	Toroidal	1.000 : 1.7	0.8	475	3.3V	N/A	5V	N/A	N/A	300	11
	SN6501,SN6505B	Texas Instruments	EPC3807G-LF	Push-Pull	Toroidal	1.000 : 1.3	0.8	475	3.3V (5V)	N/A	3.3V (5V)	N/A	N/A	300	11
	SN6501,SN6505B	Texas Instruments	EPC3808G-LF	Push-Pull	Toroidal	1.000 : 2	0.8	475	3.3V	N/A	5V	N/A	N/A	300	11
	SN6501,SN6505B	Texas Instruments	EPC3809G-LF	Push-Pull	Toroidal	1.000 : 1.1	0.8	72	5V	N/A	5V	N/A	N/A	363	8.6
