Automotive Applications and Products

The future of mobility is autonomous, and PCA Electronics, Inc. designs and manufactures complete component solutions for the automotive and transportation market.

Our product line includes transformers, inductors, and common mode chokes. We also have unique custom magnetics, all designed and manufactured to AEC-Q200 qualification standards.

Our experienced design engineers offer solutions to meet your specific needs for the current and future generations of automobiles. The size and capability of our magnetics can be designed to meet the electronics specifications your application requires.

Contact us to learn more about how PCA can optimize your automotive electronic systems.


Power Magnetics

Buy
PCA Part No.
Topology
PDF
Chipset
Controller
Geometry
Turns Ratio
Po
Lp
Vin
Aux
S1
S2
Fsw
ET
Part No.
MFG
Pri : Aux : S1 : S2 : S3
Watts
uH
Min-Max
KHz
Watts
EPA4488G-LF BMS PGA460 Texas Instruments EP5 01:08.4 0.0 3 7.2V 120 Vpk-pk 0 20
EPC3667G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.100CT 0.3 1000 3.3V N/A 3.3V / 0.1A N/A N/A 250 7.2
EPC3668G-LF Push-Pull SN6501,SN6505 Texas Instruments Toroidal 1.000CT : 1.100CT 0.8 1000 5 N/A 5V / 0.15A N/A N/A 300 9.2
EPC3669G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.700CT 0.5 475 3.3 N/A 5V / 0.1A N/A N/A 250 7.2
EPC3670G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.300CT 0.5 475 5 N/A 5V / 0.1A N/A N/A 250 9.2
EPC3671G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 2.000CT 0.5 475 3.3V N/A 5V / 0.1A N/A N/A 250 7.2
EPC3736G-LF Forward LT3725 Linear Technology EFD20 1.500 : 0.875 : 1.000 90.0 180 33 - 57V 10V / 0.05A 12V / 7.5 200
EPC3766G-LF Forward LT3725,LT4276A Linear Technology EFD20 1 : 0.75 : 0.0625 100.0 115 34 - 57V 10V / 0.05A 12V / 8.33V 200
EPC3786G-LF Forward NCP1566 On Semiconductor EFD20 1.000 : 0.580 : 0.660 84.0 180 37 - 57V 10V /0.05A 12.0V / 7.0A 250 111
EPC3789G-LF Forward LTC4269-2 Linear Technology EP13 1.000 : 0.667 : 0.278 25.0 429 30 - 60V 12V /0.01A 5.1V / 5A 225
EPC3804G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.5 900 3.3V N/A 3.3V N/A N/A 300 11
EPC3805G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.8 475 5V N/A 5V N/A N/A 300 11
EPC3806G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.7 0.8 475 3.3V N/A 5V N/A N/A 300 11
EPC3807G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.3 0.8 475 3.3V (5V) N/A 3.3V (5V) N/A N/A 300 11
EPC3808G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 2 0.8 475 3.3V N/A 5V N/A N/A 300 11
EPC3809G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.8 72 5V N/A 5V N/A N/A 363 8.6
EPF8304G-LF BMS LTC6811-1/LTC6811-2 Analog Devices Toroidal 1:01 0.0 0 - - - - - 0 -
EPF8305G-LF BMS LTC3811-2,LTC6811-1 Analog Devices Toroidal 1:01 0.0 300 0 10

Other Magnetics

Buy
PDF
PCA Part No. Inductance uH DCR (mΩ max.) Length Width Height TurnsRatio ZPeak Ω Frequency Lines Current
EP2890 0.022 0.67 0.245 0.345 0.15 2.5 0.5
EP4852 0.01 0.034 0.245 0.345 0.15 3.5 0.5
EP4853 0.015 0.48 0.245 0.345 0.15 2.5 0.5
EP4854 0.033 0.97 0.245 0.345 0.15 2.5 0.5
EP4855 0.047 1.3 0.245 0.345 0.15 2.5 0.5
EP4856 0.068 1.8 0.245 0.345 0.15 2.5 0.5
EP4857 0.1 2.55 0.245 0.345 0.15 2.5 0.42
EP4858 0.33 7.3 0.245 0.345 0.15 0.79 0.2
EP4859 0.47 9.9 0.245 0.345 0.15 0.79 0.16
EP4860 0.68 14 0.245 0.345 0.15 0.79 0.13
EPA3685-1 1000 0.65 0.75 0.375 1:1 1500 20-Jan 2
EPA3685-2 1000 0.65 0.75 0.375 1:1 2500 20-Jan 2
EPA3685-3 3000 0.65 0.75 0.375 1:1 4000 9-Jan 2
EPA3685-4 10000 0.65 0.75 0.375 1:1 5000 0.1-1 2
EPA3685-5 22000 0.65 0.75 0.375 1:1 6000 0.10-0.9 2
EPZ3109G-LF 3500 0.645 0.56 0.35 1:1 7000 0.5-3 2 2.5
EPZ3110-LF 1125 55 0.5 0.52 0.22 1:1 3000 2.0-5.0 2 1.8

Inductors

Buy
PDF
PCA Part No. Inductance DC Resistance DC Current Incrm Current amax bmax cmax dmax
EPA4468-10-LF 10 0.015 12.00 19 1.125 0.625 1.000 0.053
EPA4468-100-LF 100 0.050 7.50 7 1.375 0.860 1.000 0.053
EPA4468-150-LF 150 0.060 7.00 5 1.625 0.860 1.250 0.053
EPA4468-27-LF 27 0.025 9.00 13 0.875 0.840 0.562 0.053
EPA4468-5-LF 5 0.012 14.00 25 0.875 0.625 0.750 0.053
EPA4468-50-LF 50 0.030 8.00 10 1.125 0.840 0.750 0.053
EPA4468-68-LF 68 0.035 7.50 9 1.125 0.860 0.875 0.053
*Logos and names of other companies and products mentioned on this site are copyright and/or trademarks of their respective owners.
