MEDICAL Applications

PCA Electronics Inc. works globally with medical device firms of all sizes. Whether it's a start-up company or multi-national corporation, we provide a wide range of world-class, extremely high reliability, fully tested magnetics for a vast array of medical device technologies. Our key objective is to assist and support your design efforts from conceptual development stages through to production.

PCA's extensive engineering experience in the medical field can deliver exactly what your medical equipment application requires.

Contact us to learn how PCA magnetics can optimize your medical products.

Power Magnetics

Buy	PCA Part No.	Topology	PDF	Chipset	Controller	Geometry	Turns Ratio	Po	Lp	Vin	Aux	S1	S2	Fsw	ET
	Part No.				MFG		Pri : Aux : S1 : S2 : S3	Watts	uH	Min-Max				KHz	Watts
	EPA4488G-LF	BMS		PGA460	Texas Instruments	EP5	01:08.4	0.0	3	7.2V		120 Vpk-pk		0	20

LAN

Buy	PDF	PCA Part No.	Standard	Length	Width	Height	Inductance	TurnsRatio	Package	PackType	Product	DCR (mΩ max.)	ICMFG	ICPN
		ECT10-RC	10Base-T	0.51	0.26	0.335		1:1/1:1		SMD-16	Mini 10Base-T Interface Module with Enhanced CMA

Delay Lines

PCA Part No.	Package	DL Output	Td nS	DL Type
EP19821	14 Pin DIP	10 Tap	50	Passive
EP19822	14 Pin DIP	10 Tap	100	Passive
EP19823	14 Pin DIP	10 Tap	125	Passive
EP19824	14 Pin DIP	10 Tap	50	Passive
EP19825	14 Pin DIP	10 Tap	100	Passive
EP19826	14 Pin DIP	10 Tap	100	Passive
EP19827	14 Pin DIP	10 Tap	100	Passive
EP19828	14 Pin DIP	10 Tap	100	Passive
EP19829	14 Pin DIP	10 Tap	100	Passive
EP19830	14 Pin DIP	10 Tap	16	Passive
EP19831	14 Pin DIP	10 Tap	24	Passive
EP19833	14 Pin DIP	10 Tap	35	Passive
EP19834	14 Pin DIP	10 Tap	37	Passive
EP19835	14 Pin DIP	10 Tap	47	Passive
EP19836	14 Pin DIP	10 Tap	100	Passive
EP19838	14 Pin DIP	10 Tap	200	Passive
EP19839	14 Pin DIP	10 Tap	200	Passive

Other Magnetics

PCA Part No.	Inductance uH	DCR (mΩ max.)	Length	Width	Height	TurnsRatio	ZPeak Ω	Frequency	Lines	Current
EP151686-LF	5	0.6	0.67	0.375	0.8	50		0.020-0.050		20
EP151687A-LF	20	1.2	0.67	0.375	0.8	100		0.020-0.050		20
EP151688-LF	80	4	0.67	0.375	0.8	200		0.020-0.050		20
EP151717-LF	5	0.6	0.67	0.375	0.8	50CT		0.020-0.050		20
EP151718-LF	20	1.2	0.67	0.375	0.8	100CT		0.020-0.050		20
EP151719-LF	80	4	0.67	0.375	0.8	200CT		0.020-0.050		20
EP2890	0.022	0.67	0.245	0.345	0.15			2.5		0.5
EP4852	0.01	0.034	0.245	0.345	0.15			3.5		0.5
EP4853	0.015	0.48	0.245	0.345	0.15			2.5		0.5
EP4854	0.033	0.97	0.245	0.345	0.15			2.5		0.5
EP4855	0.047	1.3	0.245	0.345	0.15			2.5		0.5
EP4856	0.068	1.8	0.245	0.345	0.15			2.5		0.5
EP4857	0.1	2.55	0.245	0.345	0.15			2.5		0.42
EP4858	0.33	7.3	0.245	0.345	0.15			0.79		0.2
EP4859	0.47	9.9	0.245	0.345	0.15			0.79		0.16
EP4860	0.68	14	0.245	0.345	0.15			0.79		0.13
EPA3685-1	1000		0.65	0.75	0.375	1:1	1500	20-Jan	2
EPA3685-2	1000		0.65	0.75	0.375	1:1	2500	20-Jan	2
EPA3685-3	3000		0.65	0.75	0.375	1:1	4000	9-Jan	2
EPA3685-4	10000		0.65	0.75	0.375	1:1	5000	0.1-1	2
EPA3685-5	22000		0.65	0.75	0.375	1:1	6000	0.10-0.9	2
EPZ3109G-LF	3500		0.645	0.56	0.35	1:1	7000	0.5-3	2	2.5
EPZ3110-LF	1125	55	0.5	0.52	0.22	1:1	3000	2.0-5.0	2	1.8

Inductors

PCA Part No.	Inductance	DC Resistance	DC Current	Incrm Current	amax	bmax	cmax	dmax
EPA4468-10-LF	10	0.015	12.00	19	1.125	0.625	1.000	0.053
EPA4468-100-LF	100	0.050	7.50	7	1.375	0.860	1.000	0.053
EPA4468-150-LF	150	0.060	7.00	5	1.625	0.860	1.250	0.053
EPA4468-27-LF	27	0.025	9.00	13	0.875	0.840	0.562	0.053
EPA4468-5-LF	5	0.012	14.00	25	0.875	0.625	0.750	0.053
EPA4468-50-LF	50	0.030	8.00	10	1.125	0.840	0.750	0.053
EPA4468-68-LF	68	0.035	7.50	9	1.125	0.860	0.875	0.053
