Commercial Applications

PCA Electronics Inc. is perfectly suited to support the design methods that guide our commercial customers through every step of the development process. Choosing the correct magnetic component for a specific commercial application will typically require a transformer that is durable and robust to handle the demands for reliability in the commercial arena.

PCA engineers have intentionally designed in a high level of reliability to provide exceptional value for our customers and their commercial systems. Device performance is everything to our engineers.

Contact us to learn more about how PCA magnetics can optimize your commercial products.


Power Magnetics

Buy
PCA Part No.
Topology
PDF
Chipset
Controller
Geometry
Turns Ratio
Po
Lp
Vin
Aux
S1
S2
Fsw
ET
Part No.
MFG
Pri : Aux : S1 : S2 : S3
Watts
uH
Min-Max
KHz
Watts
EPA4271GE-LF Gate Drive LT4276B,LTC4269-1,LTC4278 Linear Technology Toroidal 1.000 : 1.000 0.3 785 10V 10V / 0.03A 50
EPA4452G-LF Flyback-PoE MAX253 Maxim Toroidal 1CT:1CT 0.0 1020 N/A N/A N/A 0 22
EPA4488G-LF BMS PGA460 Texas Instruments EP5 01:08.4 0.0 3 7.2V 120 Vpk-pk 0 20
EPC3115S-1-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 2.000 : 2.000 0.0 394 3.3V N/A 5V 350
EPC3115S-2-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 1.300 : 1.300 0.0 988 5V N/A 5V 350
EPC3115S-3-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 2.67 : 2.67 0.0 988 5V N/A 10V 350
EPC3115S-4-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 3.000 : 3.000 0.0 988 5V N/A 12V 350
EPC3115S-5-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 1.000 : 1.000 0.0 394 3.3V N/A 5V 350
EPC3115S-6-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 0.67 : 0.67 0.0 988 5V N/A 5V 350
EPC3115S-7-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 1.500 : 1.500 0.0 988 5V N/A 12V 350
EPC3115S-8-LF Push-Pull MAX253,MAX3535E Maxim Toroidal 1.000 : 1.000 : 2.000 : 2.000 0.0 988 5V N/A 15V 350
EPC3117S-1-LF Push-Pull MAX845 Maxim Toroidal 1.000 : 1.000 : 2.000 : 2.000 0.0 150 3.3V N/A 5V 0
EPC3117S-2-LF Push-Pull MAX845 Maxim Toroidal 1.000 : 1.000 : 1.300 : 1.300 0.0 375 5V N/A 5V 0
EPC3117S-3-LF Push-Pull MAX845 Maxim Toroidal 1.000 : 1.000 : 2.67 : 2.67 0.0 375 5V N/A 10V 0
EPC3117S-4-LF Push-Pull MAX845 Maxim Toroidal 1.000 : 1.000 : 3.000 : 3.000 0.0 375 5V N/A 12V 0
EPC3117S-8-LF Push-Pull MAX845 Maxim Toroidal 1.000 : 1.000 : 2.000 : 2.000 0.0 375 5 N/A 15V 0
EPC3126-1-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 2.000CT 0.0 500 3.3V N/A 15V 250 11
EPC3126-2-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.300CT 0.0 500 5V N/A 5V 250 11
EPC3126-3-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 2.600CT 0.0 500 5V N/A 10V 250 11
EPC3126-4-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 3.000CT 0.0 500 5V N/A 12V 250 11
EPC3126-5-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.000CT 0.0 500 3.3V N/A 5V 250 11
EPC3126-6-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 0.600CT 0.0 500 5V N/A 5V 250 11
EPC3126-7-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.500CT 0.0 500 5V N/A 12V 250 11
EPC3126G-1-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 2.000CT 0.0 500 3.3V N/A 15V 250 11
EPC3126G-2-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.300CT 0.0 500 5V N/A 5V 250 11
EPC3126G-3-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 2.600CT 0.0 500 5V N/A 10V 250 11
EPC3126G-4-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 3.000CT 0.0 500 5V N/A 12V 250 11
EPC3126G-5-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.000CT 0.0 500 3.3V N/A 5V 250 11
EPC3126G-6-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 0.600CT 0.0 500 5V N/A 5V 250 11
EPC3126G-7-LF Push-Pull MAX253,MAX845 Maxim Toroidal 1.000CT : 1.500CT 0.0 500 5V N/A 12V 250 11
EPC3127-3-LF Flyback-Offline TOP244P Power Integrations E20 5.33 : 1.08 : 1.000 17.0 475 120 - 375V 15V / 0.05A 13.55V / 1.2A N/A N/A 132
EPC3132-4A-LF Flyback-Offline LNK501 Power Integrations E13 1.000 : 0.238 2.8 2550 120 - 375V 5.5V / 0.500A 0
EPC3166G-1-LF Flyback-MultiOut LM2587/88 National Semiconductors E19 1.000 : 1.000 6.0 22 4 - 6V 3.3V / 1.8A 200
EPC3166G-2-LF Flyback-MultiOut LM2587/88 National Semiconductors E19 1.000 : 2.500 : 2.500 0.0 22 4 - 6V 12.0V / 0.3A -12V / 0.3A 200
EPC3166G-5-LF Flyback-MultiOut LM2585/86 National Semiconductors E19 1.000 : 0.500 : 1.150 : 1.150 0.0 66 18-36V 5.0V / 1.8A 12V / 0.25A -12V / 0.25A 100
EPC3166G-6-LF Flyback-MultiOut LM2585/86 National Semiconductors E19 1.000 : 1.200 : 1.200 0.0 65 4 - 6V 12.0V / 0.15A -12.0V / 0.15A 100
EPC3166G-7-LF Flyback-MultiOut LM2585/86 National Semiconductors E19 1.000 : 1.000 5.0 47 4 - 6V 3.3V / 1.4A 100
EPC3168G-1-LF Flyback-MultiOut LM2587/88 National Semiconductors RM6 1.000 : 1.000 6.0 22 4 - 6V 3.3V / 1.8A 200
EPC3168G-2-LF Flyback-MultiOut LM2587/88 National Semiconductors RM6 1.000 : 2.500 : 2.500 0.0 22 4 - 6V 12.0V / 0.3A -12V / 0.3A 200
EPC3168G-5-LF Flyback-MultiOut LM2585/86 National Semiconductors RM6 1.000 : 0.500 : 1.150 : 1.150 0.0 66 18 - 36V 5.0V / 1.8A 12V / 0.25A -12V / 0.25A 100
EPC3168G-6-LF Flyback-MultiOut LM2585/86 National Semiconductors RM6 1.000 : 1.200 : 1.200 0.0 65 4 - 6V 12.0V / 0.15A 12.0V / 0.15A 100
EPC3168G-7-LF Flyback-MultiOut LM2585/86 National Semiconductors RM6 1.000 : 1.000 5.0 47 4 - 6V 3.3V / 1.4A 100
EPC3169-3-LF Flyback-MultiOut LM2587/88 National Semiconductors E25 1.000 : 0.800 : 0.800 0.0 85 18 - 36V 12V / 1.0A -12V / 1.0A 200
EPC3169-4-LF Flyback-MultiOut LM2587/88 National Semiconductors E25 1.000 : 0.350 : 0.800 : 0.800 0.0 85 18 - 36V 5V / 2.5A 12V / 0.5A -12V / 0.5A 200
EPC3205G-10-LF Flyback-Trigger LT3750 Linear Technology EE5.0 1.000 : 10.400 0.0 4 5.0 - 7.0V N/A 400V N/A 0
EPC3205G-11-LF Flyback-Trigger LT3420 Linear Technology Toroidal 1.000 : 16.000 0.0 24 1.8 - 5.0V N/A 320V N/A 0
EPC3205G-1A-LF Flyback-Trigger LT3468 Linear Technology Toroidal 1.000 : 10.200 0.0 20 2.5 - 5.0V N/A 320V N/A 0
EPC3205G-2-LF Flyback-Trigger LT3468 Linear Technology Toroidal 1.000 : 10.200 0.0 12 2.5 - 5.0V N/A 320V N/A 0
EPC3205G-3-LF Flyback-Trigger LT3468 Linear Technology Toroidal 1.000 : 10.200 0.0 10 2.5 - 4.0V N/A 320V N/A 0
EPC3205G-4-LF Flyback-Trigger LT3468 Linear Technology EE5.0 1.000 : 10.200 0.0 10 2.5 - 5.0V N/A 320V N/A 0
EPC3205G-5-LF Flyback-Trigger LT3468 Linear Technology EE5.0 1.000 : 10.200 0.0 15 2.5 - 5.0V N/A 320V N/A 0
EPC3205G-6-LF Flyback-Trigger LT3420 Linear Technology EE5.0 1.000 : 12.000 0.0 25 1.8 - 5.0V N/A 320V N/A 0
EPC3205G-7-LF Flyback-Trigger LT3420 Linear Technology EPC10 1.000 : 12.000 0.0 24 1.8 - 6.0V N/A 320V N/A 0
EPC3205G-8-LF Flyback-Trigger LT3420 Linear Technology Toroidal 1.000 : 10.200 0.0 15 1.8 - 5.0V N/A 320V N/A 0
EPC3205G-9-LF Flyback-Trigger LT3420 Linear Technology Toroidal 1.000 : 12.000 0.0 25 1.8 - 5.0V N/A 320V N/A 0
EPC3245-1 PFC Boost EF20 N/A 70.0 2000 85 - 265Vac N/A N/A N/A N/A 200
EPC3245-10 PFC Boost E32 N/A 310.0 1000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-11 PFC Boost ER28 N/A 310.0 500 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-12 PFC Boost ER28L N/A 310.0 1000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-13 PFC Boost ER35 N/A 430.0 500 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-14 PFC Boost ER35L N/A 430.0 1000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-15 PFC Boost ETD44 N/A 550.0 1000 85 - 265Vac N/A N/A N/A N/A 50
EPC3245-16 PFC Boost ETD44 N/A 550.0 500 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-17 PFC Boost ETD44 N/A 550.0 1000 85 - 265Vac N/A N/A N/A N/A 50
EPC3245-18 PFC Boost ETD44 N/A 550.0 500 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-2 PFC Boost EF20 N/A 70.0 2000 85 - 265Vac N/A N/A N/A N/A 200
EPC3245-3 PFC Boost E30 N/A 190.0 2000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-4 PFC Boost E30 N/A 190.0 2000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-5 PFC Boost Toroidal N/A 190.0 1000 85 - 265Vac N/A N/A N/A N/A 200
EPC3245-6 PFC Boost Toroidal N/A 190.0 2000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-7 PFC Boost Toroidal N/A 190.0 1000 85 - 265Vac N/A N/A N/A N/A 200
EPC3245-8 PFC Boost Toroidal N/A 190.0 2000 85 - 265Vac N/A N/A N/A N/A 100
EPC3245-9 PFC Boost E31 N/A 310.0 500 85 - 265Vac N/A N/A N/A N/A 100
EPC3246-1 PFC Boost EF20 19.8 : 1.000 70.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 200
EPC3246-10 PFC Boost E32 18.25 : 1.000 310.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-11 PFC Boost ER28 18.25 : 1.000 310.0 500 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-12 PFC Boost ER28L 18.25 : 1.000 310.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-13 PFC Boost ER35 17.86 : 1.000 430.0 500 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-14 PFC Boost ER35L 17.86 : 1.000 430.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-15 PFC Boost ETD44 19.17 : 1.000 550.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 50
EPC3246-16 PFC Boost ETD44 18.75 : 1.000 550.0 500 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-17 PFC Boost ETD44 19.17 : 1.000 550.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 50
EPC3246-18 PFC Boost ETD44 18.75 : 1.000 550.0 500 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-2 PFC Boost EF20 19.8 : 1.000 70.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 200
EPC3246-3 PFC Boost E30 20.0 : 1.000 190.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-4 PFC Boost E30 20.0 : 1.000 190.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-5 PFC Boost Toroidal 19.67 : 1.000 190.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 200
EPC3246-6 PFC Boost Toroidal 19.59 : 1.000 190.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-7 PFC Boost Toroidal 19.67 : 1.000 190.0 1000 85 - 265Vac 20V / 0.15A N/A N/A N/A 200
EPC3246-8 PFC Boost Toroidal 19.59 : 1.000 190.0 2000 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3246-9 PFC Boost E31 18.25 : 1.000 310.0 500 85 - 265Vac 20V / 0.15A N/A N/A N/A 100
EPC3356G-3.3-LF Flyback-PoE EP13 1.000 : 0.500 : 0.166 13.0 127 36-72V 12 3.3V / 3.0A 250
EPC3391G-LF Flyback-PoE LT1725 Linear Technology EFD20 1.000 : 0.417 : 1.111 45.0 42 36 - 57V 15V / 0.01A 36V / 1.25A 0
EPC3394G-LF Flyback-PoE LT1725 Linear Technology EFD25 1.000 : 0.417 : 1.000 45.0 42 36 - 57V 15V / 0.01A 36V / 1.25A 200
EPC3408G-LF Flyback-PoE LT4276B,LTC4269-1 Linear Technology EP13 1.670 : 1.000 : 0.250 : 0.250 25.0 38 36 - 57V 12V / 0.02A 3.3V / 7 250
EPC3409G-LF Flyback-PoE LT4276B,LTC4269-1 Linear Technology EP13 2.000 : 1.000 : 0.400 : 0.400 25.0 39 36 - 57V 12V / 0.02A 5V / 5A 250
EPC3410G-LF Flyback-PoE LT4276B,LTC4269-1 Linear Technology EP13 1.800 : 1.000 : 0.900 25.0 37 36 - 57V 12V / 0.02A 12V / 2A 250
EPC3472G-LF Flyback-PoE LTC4278 Linear Technology EFD20 1.000 : 0.750 : 0.375 25.0 9 9 - 57V 10V / 0.03A 5V / 5A 250
EPC3479G-LF Flyback-PoE LTC4278 Linear Technology EFD20 1.000 : 0.750 : 0.250 25.0 9 9 - 57V 10V / 0.03A 3.3V / 7.5A 250
EPC3492G-LF Flyback-PoE LTC4278 Linear Technology EFD20 1.000 : 0.750 : 1.750 24.0 9 10 - 57V 10V / 0.03A 24V / 1A 250
EPC3508GE-LF Flyback-PoE LTC4278 Linear Technology EFD20 1.000 : 0.750 : 0.875 24.0 9 9 - 57V 10V / 0.03A 12V / 2A 250
EPC3546G-LF Flyback-PoE LTC4278 Linear Technology EFD20 1.000 : 0.750 : 3.375 24.0 9 9V - 57V 10V / 0.03A 48V / 0.5A 250
EPC3575G-LF Flyback-PoE LT4269-1 Linear Technology EP13 7.330 : 2.330 : 1.000 40.0 35 36 - 57V 12V / 0.20A 5V / 8A 0
EPC3577G-LF Forward LT4276A,LT4295 Linear Technology EFD20 1.500 : 0.875 : 1.000 90.0 180 33 - 57V 10V / 0.05A 12V / 7.5 200
EPC3577G-LF Flyback-PoE LT4276A,LT4295 Linear Technology EFD20 1.500 : 0.875 : 1.000 90.0 180 33 - 57V 10V / 0.05A 12V / 7.5 200
EPC3586G-LF Flyback-PoE LT4276B,LTC4269-1 Linear Technology EP13 1.800 : 1.000 : 0.400 : 0.400 35.0 26 48 - 57V 12V / 0.01A 5V / 7A 250
EPC3599G-LF Forward LTC3725 Linear Technology EFD20 3.500 : 1.000 65.0 240 40 - 57V N/A 5V / 13A 250
EPC3601G-LF Flyback-PoE LT4276,LT4295,LTC4278 Linear Technology EFFD20 1.000 : 1.000 : 1.125 25.0 9 9 - 57V 10V / 0.03A 12V / 2A 250
EPC3603G-LF Flyback-PoE LT4276B,LTC4269-1 Linear Technology EP13 1.800 : 1.000 : 1.800 : 1.800 25.0 37 40 - 57V 12.5V / 0.01A 24V / 1A 250
EPC3625G-LF Flyback-PoE LT4295 Linear Technology EFD25 8.000 : 3.000 : 4.000 : 4.000 96.0 13 40 - 57V 9V / 0.03A 12V / 4A 12V / 4A 250
EPC3630G-LF Flyback-PoE LT4295 Linear Technology EFD25 8.000 : 8:000 : 3.000 84.0 15 40 - 57V 9V / 0.03A 24V / 3.5A 250
EPC3633G-LF Flyback-PoE LT4295 Linear Technology EFD20 1.000 : 0.500 : 0.500 48.0 18 41 - 57V 12V / 0.03A 12V / 4A 250
EPC3634AG-LF Flyback-PoE LT4295 Linear Technology EP13 1.000 : 0.500 : 0.440 36.0 26 42 - 57V 12V / 0.01A 12V / 3A 250
EPC3636G-LF Forward LT4295 Linear Technology EFD20 2.000 : 1.330 : 0.500 : 2.660 72.0 180 40 - 57V 10V / 0.02A 3.3V / 0.05A 24V / 3A 250
EPC3648GE-LF Flyback-Converter LT3574,LTC3575-1,LTC3748 Linear Technology EP10 1.000 : 1.000 : 0.333 12.0 100 36 8.0V / 0.20A 24.0V / 0.500A 100
EPC3667G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.100CT 0.3 1000 3.3V N/A 3.3V / 0.1A N/A N/A 250 7.2
EPC3668G-LF Push-Pull SN6501,SN6505 Texas Instruments Toroidal 1.000CT : 1.100CT 0.8 1000 5 N/A 5V / 0.15A N/A N/A 300 9.2
EPC3669G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.700CT 0.5 475 3.3 N/A 5V / 0.1A N/A N/A 250 7.2
EPC3670G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 1.300CT 0.5 475 5 N/A 5V / 0.1A N/A N/A 250 9.2
EPC3671G-LF Push-Pull SN6501 Texas Instruments Toroidal 1.000CT : 2.000CT 0.5 475 3.3V N/A 5V / 0.1A N/A N/A 250 7.2
EPC3680G-LF Flyback-PoE LT4267 Linear Technology EP10 1.000 : 0.208 : 0.083 7.0 253 33 - 57V 8V / 0.02A 3.3V / 2A 200
EPC3681G-LF Flyback-PoE LT4267 Linear Technology EP13 1.000 : 0.208 : 0.083 13.5 127 33 - 57 8V / 0.02A 3.3V / 4A 200
EPC3682GE-LF Forward-PoE LT4276,LT4295 Linear Technology EFD20 1.000 : 0.641 : 0.289 85.0 175 40 - 57 10.75 5V / 17A 250
EPC3683GE-LF Flyback-PoE LT4276,LT4295 Linear Technology EP7 4.000 : 2.500 : 1.000 11.5 44 36 - 57 12 5.0V / 2.3A 250
EPC3688G-LF Flyback-Converter LT8301 Linear Technology EP10 3.000 : 0.000 :1.000 3.0 40 10 - 38V N/A 5.0V / 0.60A 200
EPC3736G-LF Forward LT3725 Linear Technology EFD20 1.500 : 0.875 : 1.000 90.0 180 33 - 57V 10V / 0.05A 12V / 7.5 200
EPC3766G-LF Forward LT3725,LT4276A Linear Technology EFD20 1 : 0.75 : 0.0625 100.0 115 34 - 57V 10V / 0.05A 12V / 8.33V 200
EPC3776G-LF Flyback-Converter EFD15 1.000 : 0.167 : 0.167 6.0 44 8V - 20V 3.3 1340V / 0.011A N/A 60 N/A
EPC3786G-LF Forward NCP1566 On Semiconductor EFD20 1.000 : 0.580 : 0.660 84.0 180 37 - 57V 10V /0.05A 12.0V / 7.0A 250 111
EPC3789G-LF Forward LTC4269-2 Linear Technology EP13 1.000 : 0.667 : 0.278 25.0 429 30 - 60V 12V /0.01A 5.1V / 5A 225
EPC3804G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.5 900 3.3V N/A 3.3V N/A N/A 300 11
EPC3805G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.8 475 5V N/A 5V N/A N/A 300 11
EPC3806G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.7 0.8 475 3.3V N/A 5V N/A N/A 300 11
EPC3807G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.3 0.8 475 3.3V (5V) N/A 3.3V (5V) N/A N/A 300 11
EPC3808G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 2 0.8 475 3.3V N/A 5V N/A N/A 300 11
EPC3809G-LF Push-Pull SN6501,SN6505B Texas Instruments Toroidal 1.000 : 1.1 0.8 72 5V N/A 5V N/A N/A 363 8.6
EPC3901G-LF Flyback-Converter LT8304 Linear Technology EP10 1.000 : 0.500 : 0.233 6.0 40 8 - 56V 5.0V / 0.480A 12.0V / 0.30A 200
EPF8304G-LF BMS LTC6811-1/LTC6811-2 Analog Devices Toroidal 1:01 0.0 0 - - - - - 0 -

LAN

Buy
PDF
 PCA Part No. Standard Length Width Height Inductance TurnsRatio Package PackType Product
DCR (mΩ max.)
ICMFG
ICPN
ECT10 10Base-T 0.51 0.26 0.335 1:1/1:1 SMD-16 Mini 10Base-T Interface Module with Enhanced CMA
ECT10-RC 10Base-T 0.51 0.26 0.335 1:1/1:1 SMD-16 Mini 10Base-T Interface Module with Enhanced CMA
EP9531-1-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-10-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-11-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-12-RC Isolation Transformers 0.79 0.27 0.16 300µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-13 Isolation Transformers 0.79 0.27 0.16 350µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-13-RC Isolation Transformers 0.79 0.27 0.16 350µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4
EP9531-15-RC Isolation Transformers 0.79 0.27 0.16 335µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4
EP9531-2-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-3 Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-3-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-4 Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-4-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-5 Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-5-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-5X Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-6-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-6X Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-7-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-8 Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-8-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531-8X Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531-9-RC Isolation Transformers 0.79 0.27 0.16 250µH 1:01 DIP-16 LAN Ethernet Isolation Transformer 4.5
EP9531G-3 Isolation Transformers 0.79 0.27 0.16 35µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531G-4 Isolation Transformers 0.79 0.27 0.16 50µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EP9531G-8 Isolation Transformers 0.79 0.27 0.16 150µH 1:01 DIP-16 LAN Ethernet Isolation Transformer
EPA045-1 Isolation Transformers 0.5 0.35 0.118 2µH 1:01 Thru Hole-4 LAN Ethernet Isolation Transformer 1
EPA045-2 Isolation Transformers 0.79 0.385 0.115 2µH 1:01 Thru Hole-14 LAN Ethernet Isolation Transformer 1
EPA045-3 Isolation Transformers 0.5 0.35 0.118 2µH 1:01 Thru Hole-4 LAN Ethernet Isolation Transformer 1
EPA1473J-1 Isolation Transformers 0.44 0.28 0.178 25µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.15
EPA1473J-2 Isolation Transformers 0.44 0.28 0.178 30µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.15
EPA1473J-3 Isolation Transformers 0.44 0.28 0.178 35µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.2
EPA1473J-4 Isolation Transformers 0.44 0.28 0.178 50µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.2
EPA1473J-5 Isolation Transformers 0.44 0.28 0.178 75µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.3
EPA1473J-6 Isolation Transformers 0.44 0.28 0.178 100µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.3
EPA1473J-7 Isolation Transformers 0.44 0.28 0.178 125v 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.3
EPA1473J-8 Isolation Transformers 0.44 0.28 0.178 150µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.4
EPA1473J-9 Isolation Transformers 0.44 0.28 0.178 175µH 1:01 SOIC/J-16 LAN Ethernet Isolation Transformer 0.5
EPA1885-1 10Base-T 0.45 0.25 0.22 25µH 1:01 SMD-16 LAN Ethernet Isolation Transformer 0.15
EPA1885-10 10Base-T 0.45 0.25 0.22 200µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-15 10Base-T 0.45 0.25 0.22 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-16 10Base-T 0.45 0.25 0.22 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-17 10Base-T 0.45 0.25 0.22 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-2 10Base-T 0.45 0.25 0.22 30µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-3 10Base-T 0.45 0.25 0.22 35µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-4 10Base-T 0.45 0.25 0.22 50µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-5 10Base-T 0.45 0.25 0.22 75µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-6 10Base-T 0.45 0.25 0.22 100µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-6 10Base-T 0.45 0.25 0.22 100µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-7 10Base-T 0.45 0.25 0.22 125µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-8 10Base-T 0.45 0.25 0.22 150µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA1885-9 10Base-T 0.45 0.25 0.22 175µH 1:01 SMD-16 LAN Ethernet Isolation Transformer
EPA2116G 10Base-T 0.9 0.38 0.45 1:1/1:1 SMD-16 10Base-T Interface Module with Enhanced CMA & Resistor
EPA2864GE 25 Mb ATM Xmit/Recv 1 0.37 0.4 1:1:1:1 SMD-16 Isolation Transformer
EPE6059G 10Base-T 0.8 0.53 0.88 1:01 SMD-12 10Base-T Interface Module
EPE6059GM 10Base-T 0.8 0.53 0.88 1:01 SMD-12 10Base-T Interface Module
EPE6066 10Base-T 1.24 0.33 0.43 1:1/1:1 SIL-12 10Base-T Hub Module with Enhanced CMA & Resistor Network AM79C965
EPF8119S-RC 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SOIC-16 10/100 LAN Interface Module for NIC/HUB Applications
EPF8119SE 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SOIC-16 10/100 LAN Interface Module for NIC/HUB Applications
EPF8119SE-RC 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SOIC-16 10/100 LAN Interface Module for NIC/HUB Applications
EPF8119SH 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SOIC-16 10/100 LAN Interface Module for NIC/HUB Applications
EPF8135S 10/100Base-TX 1.12 0.48 0.26 350µH 1:1/2CT:1CT SMD-40 10/100Base-TX Module for Dual-Port Applications
EPF8143S 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SMD-16 10/100 LAN Interface Module with Enhanced Common Mode Attenuation
EPF8143S-RC 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SMD-16 10/100 LAN Interface Module with Enhanced Common Mode Attenuation
EPF8143SE 10/100Base-TX 0.5 0.28 0.2 350µH 1CT:1CT/1CT:1CT SMD-16 10/100 LAN Interface Module with Enhanced Common Mode Attenuation
EPF8275GE 10/100Base-TX 0.59 0.66 0.34 350µH 1CT:1CT SMD-12 10/100 LAN Interface Module with PoE Capability up to 1Adc Linear Technology LTC4269-1,LTC4278
EPF8275GE-LF 10/100Base-TX 0.59 0.66 0.34 350µH 1CT:1CT SMD-12 10/100 LAN Interface Module with PoE Capability up to 1Adc Linear Technology LTC4269-1,LTC4278
EPF8291SE-LF 10/100Base-TX 0.27 0.49 0.2 350µH 1CT:1CT SMD-16 10/100Base-TX Interface Module
EPG4000S 1000Base-T 0.73 0.49 0.27 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4000SLH 1000Base-T 0.73 0.49 0.27 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4001AS 1000Base-T 0.7 0.49 0.27 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4001AS-RC 1000Base-T 0.7 0.49 0.27 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4001CS 1000Base-T 0.69 0.48 0.26 350µH 1CT:1CT SOIC-24 1000Base-T Module with Enhanced Common Mode Choke
EPG4001S 1000Base-T 0.7 0.49 0.27 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4004 1000Base-T 0.55 0.61 0.235 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4004F 1000Base-T 0.55 0.61 0.235 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4004F-RC 1000Base-T 0.55 0.61 0.235 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4005 1000Base-T 0.55 0.61 0.235 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4006F 1000Base-T 1.15 0.49 0.27 350µH 1CT:1CT SOIC-48 1000Base-T Module
EPG4009F 1000Base-T 1.105 0.49 0.295 350µH 1CT:1CT SOIC-48 1000Base-T Module
EPG4010F 1000Base-T 1.105 0.49 0.27 350µH 1CT:1CT SOIC-48 1000Base-T Module
EPG4011J 1000Base-T 0.73 0.285 0.375 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4012J 1000Base-T 0.73 0.285 0.375 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4013S 1000Base-T 0.69 0.48 0.175 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4014S 1000Base-T 0.69 0.48 0.175 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4014SE-LF 1000Base-T 0.69 0.48 0.175 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4016F 1000Base-T 0.54 0.6 0.225 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4017F 1000Base-T 1.09 0.43 1.15 350µH 1CT:1CT SOIC-50 1000Base-T Module
EPG4017F-RC 1000Base-T 1.09 0.43 1.15 350µH 1CT:1CT SMD-50 1000Base-T Module
EPG4025F 1000Base-T 1.09 0.43 0.33 350µH 1CT:1CT SOIC-50 1000Base-T Module Dual Port VOIP Magnetic Module
EPG4025F-RC 1000Base-T 1.09 0.43 0.33 350µH 1CT:1CT SOIC-50 1000Base-T Module Dual Port VOIP Magnetic Module
EPG4254JE-LF 1000Base-T 0.73 0.305 0.393 350µH 1CT:1CT SOIC-24 1000Base-T Module
EPG4260S-LF 1000Base-T 0.71 0.504 0.4 350µH 1CT:1CT SOIC-24 PoE Data Transformer

Delay Lines

Buy
PDF
 PCA Part No. Package DL Output Td nS DL Type
EP120650 7 Pin SIL 5 Tap 5 Passive
EP120651 7 Pin SIL 5 Tap 10 Passive
EP120652 7 Pin SIL 5 Tap 20 Passive
EP120653 7 Pin SIL 5 Tap 30 Passive
EP120654 7 Pin SIL 5 Tap 40 Passive
EP120655 7 Pin SIL 5 Tap 50 Passive
EP120656 7 Pin SIL 5 Tap 60 Passive
EP120657 7 Pin SIL 5 Tap 70 Passive
EP120658 7 Pin SIL 5 Tap 80 Passive
EP120659 7 Pin SIL 5 Tap 90 Passive
EP120660 7 Pin SIL 5 Tap 100 Passive
EP120661 7 Pin SIL 5 Tap 5 Passive
EP120662 7 Pin SIL 5 Tap 10 Passive
EP120663 7 Pin SIL 5 Tap 20 Passive
EP120664 7 Pin SIL 5 Tap 30 Passive
EP120665 7 Pin SIL 5 Tap 40 Passive
EP120666 7 Pin SIL 5 Tap 50 Passive
EP120667 7 Pin SIL 5 Tap 60 Passive
EP120668 7 Pin SIL 5 Tap 70 Passive
EP120669 7 Pin SIL 5 Tap 80 Passive
EP120670 7 Pin SIL 5 Tap 90 Passive
EP120671 7 Pin SIL 5 Tap 100 Passive
EP1206XX 7 Pin SIL 5 Tap 5-100 Passive
EP123112 8 Pin SIL Single 5.5 Passive
EP123113 8 Pin SIL Single 6 Passive
EP123115 8 Pin SIL Single 7 Passive
EP1231XX 8 Pin SIL Single 0-45 Passive
EP19821 14 Pin DIP 10 Tap 50 Passive
EP19822 14 Pin DIP 10 Tap 100 Passive
EP19823 14 Pin DIP 10 Tap 125 Passive
EP19824 14 Pin DIP 10 Tap 50 Passive
EP19825 14 Pin DIP 10 Tap 100 Passive
EP19826 14 Pin DIP 10 Tap 100 Passive
EP19827 14 Pin DIP 10 Tap 100 Passive
EP19828 14 Pin DIP 10 Tap 100 Passive
EP19829 14 Pin DIP 10 Tap 100 Passive
EP19830 14 Pin DIP 10 Tap 16 Passive
EP19831 14 Pin DIP 10 Tap 24 Passive
EP19833 14 Pin DIP 10 Tap 35 Passive
EP19834 14 Pin DIP 10 Tap 37 Passive
EP19835 14 Pin DIP 10 Tap 47 Passive
EP19836 14 Pin DIP 10 Tap 100 Passive
EP19838 14 Pin DIP 10 Tap 200 Passive
EP19839 14 Pin DIP 10 Tap 200 Passive

Other Magnetics

Buy
PDF
 PCA Part No. Inductance uH DCR (mΩ max.) Length Width Height TurnsRatio ZPeak Ω Frequency Lines Current
EP151686-LF 5 0.6 0.67 0.375 0.8 50 0.020-0.050 20
EP151687A-LF 20 1.2 0.67 0.375 0.8 100 0.020-0.050 20
EP151688-LF 80 4 0.67 0.375 0.8 200 0.020-0.050 20
EP151717-LF 5 0.6 0.67 0.375 0.8 50CT 0.020-0.050 20
EP151718-LF 20 1.2 0.67 0.375 0.8 100CT 0.020-0.050 20
EP151719-LF 80 4 0.67 0.375 0.8 200CT 0.020-0.050 20
EP2890 0.022 0.67 0.245 0.345 0.15 2.5 0.5
EP4852 0.01 0.034 0.245 0.345 0.15 3.5 0.5
EP4853 0.015 0.48 0.245 0.345 0.15 2.5 0.5
EP4854 0.033 0.97 0.245 0.345 0.15 2.5 0.5
EP4855 0.047 1.3 0.245 0.345 0.15 2.5 0.5
EP4856 0.068 1.8 0.245 0.345 0.15 2.5 0.5
EP4857 0.1 2.55 0.245 0.345 0.15 2.5 0.42
EP4858 0.33 7.3 0.245 0.345 0.15 0.79 0.2
EP4859 0.47 9.9 0.245 0.345 0.15 0.79 0.16
EP4860 0.68 14 0.245 0.345 0.15 0.79 0.13
EPA120 20 0.42 0.28 0.175 425 50-70 4 1
EPA120G 20 0.41 0.28 0.175 425 50-70 4 1
EPA2163 85 0.21 0.27 0.22 900 25-Oct 2
EPA2165 85 0.24 0.25 0.22 1:1:1:1 1200 Oct-40 4
EPA2165S 85 0.24 0.25 0.22 1:1:1:1 1200 Oct-40 4
EPA2165S-RC 85 0.24 0.25 0.22 1:1:1:1 1200 Oct-40 4
EPA2165SE 85 0.24 0.25 0.22 1:1:1:1 1200 Oct-40 4
EPA2165SE-RC 85 0.24 0.25 0.22 1:1:1:1 1200 Oct-40 4
EPA3685-1 1000 0.65 0.75 0.375 1:1 1500 20-Jan 2
EPA3685-2 1000 0.65 0.75 0.375 1:1 2500 20-Jan 2
EPA3685-3 3000 0.65 0.75 0.375 1:1 4000 9-Jan 2
EPA3685-4 10000 0.65 0.75 0.375 1:1 5000 0.1-1 2
EPA3685-5 22000 0.65 0.75 0.375 1:1 6000 0.10-0.9 2
EPC3108G-100 2000 6.2 0.33 0.26 0.21 1:100 0.25 6
EPC3108G-125 3 7.7 0.33 0.26 0.21 1:125 0.25 6
EPC3108G-30 0.18 1 0.33 0.26 0.21 1:3 0.25 6
EPC3108G-40 0.32 1.35 0.33 0.26 0.21 1:4 0.25 6
EPC3108G-50 500 2.5 0.33 0.26 0.21 1:5 0.25 6
EPC3108G-70 980 4.75 0.33 0.26 0.21 1:7 0.25 6
EPC3108G-85 1430 5.3 0.33 0.26 0.21 1:85 0.25 6
EPZ3109G-LF 3500 0.645 0.56 0.35 1:1 7000 0.5-3 2 2.5
EPZ3110-LF 1125 55 0.5 0.52 0.22 1:1 3000 2.0-5.0 2 1.8

Inductors

Buy
PDF
 PCA Part No. Inductance DC Resistance DC Current Incrm Current amax bmax cmax dmax
EPA4468-10-LF 10 0.015 12.00 19 1.125 0.625 1.000 0.053
EPA4468-100-LF 100 0.050 7.50 7 1.375 0.860 1.000 0.053
EPA4468-150-LF 150 0.060 7.00 5 1.625 0.860 1.250 0.053
EPA4468-27-LF 27 0.025 9.00 13 0.875 0.840 0.562 0.053
EPA4468-5-LF 5 0.012 14.00 25 0.875 0.625 0.750 0.053
EPA4468-50-LF 50 0.030 8.00 10 1.125 0.840 0.750 0.053
EPA4468-68-LF 68 0.035 7.50 9 1.125 0.860 0.875 0.053
*Logos and names of other companies and products mentioned on this site are copyright and/or trademarks of their respective owners.



ISO9001:2015 REGISTERED

ISO9001:2015 certifications in all of our global sales and manufacturing facilities.

CAREER OPPORTUNITIES

PCA® has a career opening for a Power Products/Sales Engineer.

If you’re interested in this position, view the job requirements here.

ABOUT PCA®

About Us / Quality Policy
Line Card
Presentation - Watch or D/L PDF
Compliance/Resources
  Contact

CONTACT US

PCA® Electronics Inc.
16799 Schoenborn Street
North Hills, CA 91343
  888-892-0761      818-894-5791
  Sales/Product Inquiry

Site Map | Contact | Terms of Use | Privacy Policy
Follow Us on
©2024 PCA Electronics, Inc. All Rights Reserved.
