Aerospace Applications

PCA Electronics Inc. has over 70 years of experience designing and manufacturing military grade magnetics to support various demanding platforms used by all branches of the armed forces.

PCA has the expertise to ensure product compliance with requisite military and industry standards, providing customers with the highest reliability solutions and confidence in delivered products.

Contact us to learn more about how the PCA team can optimize your aerospace products.


Power Magnetics

Buy
PCA Part No.
Topology
PDF
Chipset
Controller
Geometry
Turns Ratio
Po
Lp
Vin
Aux
S1
S2
Fsw
ET
Part No.
MFG
Pri : Aux : S1 : S2 : S3
Watts
uH
Min-Max
KHz
Watts
EPA4488G-LF BMS PGA460 Texas Instruments EP5 01:08.4 0.0 3 7.2V 120 Vpk-pk 0 20

LAN

Buy
PDF
 PCA Part No. Standard Length Width Height Inductance TurnsRatio Package PackType Product
DCR (mΩ max.)
ICMFG
ICPN
ECT10 10Base-T 0.51 0.26 0.335 1:1/1:1 SMD-16 Mini 10Base-T Interface Module with Enhanced CMA
ECT10-RC 10Base-T 0.51 0.26 0.335 1:1/1:1 SMD-16 Mini 10Base-T Interface Module with Enhanced CMA
EPA2864GE 25 Mb ATM Xmit/Recv 1 0.37 0.4 1:1:1:1 SMD-16 Isolation Transformer

Delay Lines

Buy
PDF
 PCA Part No. Package DL Output Td nS DL Type
EP19821 14 Pin DIP 10 Tap 50 Passive
EP19822 14 Pin DIP 10 Tap 100 Passive
EP19823 14 Pin DIP 10 Tap 125 Passive
EP19824 14 Pin DIP 10 Tap 50 Passive
EP19825 14 Pin DIP 10 Tap 100 Passive
EP19826 14 Pin DIP 10 Tap 100 Passive
EP19827 14 Pin DIP 10 Tap 100 Passive
EP19828 14 Pin DIP 10 Tap 100 Passive
EP19829 14 Pin DIP 10 Tap 100 Passive
EP19830 14 Pin DIP 10 Tap 16 Passive
EP19831 14 Pin DIP 10 Tap 24 Passive
EP19833 14 Pin DIP 10 Tap 35 Passive
EP19834 14 Pin DIP 10 Tap 37 Passive
EP19835 14 Pin DIP 10 Tap 47 Passive
EP19836 14 Pin DIP 10 Tap 100 Passive
EP19838 14 Pin DIP 10 Tap 200 Passive
EP19839 14 Pin DIP 10 Tap 200 Passive

Other Magnetics

Buy
PDF
 PCA Part No. Inductance uH DCR (mΩ max.) Length Width Height TurnsRatio ZPeak Ω Frequency Lines Current
EP151686-LF 5 0.6 0.67 0.375 0.8 50 0.020-0.050 20
EP151687A-LF 20 1.2 0.67 0.375 0.8 100 0.020-0.050 20
EP151688-LF 80 4 0.67 0.375 0.8 200 0.020-0.050 20
EP151717-LF 5 0.6 0.67 0.375 0.8 50CT 0.020-0.050 20
EP151718-LF 20 1.2 0.67 0.375 0.8 100CT 0.020-0.050 20
EP151719-LF 80 4 0.67 0.375 0.8 200CT 0.020-0.050 20
EP2890 0.022 0.67 0.245 0.345 0.15 2.5 0.5
EP4852 0.01 0.034 0.245 0.345 0.15 3.5 0.5
EP4853 0.015 0.48 0.245 0.345 0.15 2.5 0.5
EP4854 0.033 0.97 0.245 0.345 0.15 2.5 0.5
EP4855 0.047 1.3 0.245 0.345 0.15 2.5 0.5
EP4856 0.068 1.8 0.245 0.345 0.15 2.5 0.5
EP4857 0.1 2.55 0.245 0.345 0.15 2.5 0.42
EP4858 0.33 7.3 0.245 0.345 0.15 0.79 0.2
EP4859 0.47 9.9 0.245 0.345 0.15 0.79 0.16
EP4860 0.68 14 0.245 0.345 0.15 0.79 0.13
EPZ3109G-LF 3500 0.645 0.56 0.35 1:1 7000 0.5-3 2 2.5
